Quick overview from the supplier:
Case ATX Chieftec Visio AIR, w/o PSU, 0,65/0.9mm, 3x140mm, Front Mesh, Tempered Glass, Dual-chamber, 1xUSB-C, 2xUSB3.0, 2x2,5", 2x3,5", Black
.
PN: GM-30B-M-OP
Model Visio AIR
Article no. GM-30B-M-OP
EAN code 0753263078704
Color Black
Material 0.65-0.9mm SPCC and tempered glass at side panel
Motherboard support Mini ITX, mATX, ATX
Dimension (DxWxH) 430mm x 295mm x 390mm
Weight (without/with package) 6.8 kg / 8.3 kg
Drive bay external --
Drive bay internal 2x 2.5" and 2x 3.5“
Power supply ATX PSU (optional, ~200mm)
Front I/O 1x USB3.2 Gen2 Type C, 2 x USB3.0, Audio-out (AZALIA / HD-Audio), Mic-In
Scope of delivery Set of screws, instruction manual
Bottom: 2x 140mm PWM fans pre-installed
Rear: 1x 140mm PWM fan pre-installed
Expansion slots 6
Cooling Compatibility Bottom: 3x 120mm / 2x 140mm / 240mm radiator / 280mm radiator / 360mm radiator
Top: 3x 120mm / 2x 140mm / 240mm radiator / 280mm radiator / 360 mm radiator
M/B side: 2x 120mm / 240mm radiator
Rear: 1x 120mm / 1x 140mm
CPU cooler height (max.) 175mm
VGA card length (max.) 410mm
