Quick overview from the supplier:
Case ATX NZXT H5 Flow RGB (2024), 1x360mm RGB & 1x120mm, Front&Top Mesh, Tempered Glass, Dust Filter, 1xUSB 3.2, 1xUSB-C, 1x3.5", 2x2.5", White
.
PN: CC-H52FW-R1
Key Specs
Motherboard Support E-ATX (Up to 277 mm wide), ATX, Micro-ATX, Mini-ITX
Enclosure Type Mid-Tower
Case Material SGCC Steel, Ultra-Clear Tempered Glass (White), Dark Tinted Tempered Glass (Black)
Dimensions
Height (with feet) 465 mm / 18.31 in
Width 225 mm / 8.86 in
Depth 430 mm / 16.93 in
Weight 7.63 kg / 16.82 lb
Compatibility & Clearance
CPU Cooler Height Up to 170 mm
GPU Length Up to 410 mm
PSU Length Up to 200 mm
Cable Management Up to 28.7 mm
Top Radiator Up to 240 mm (280 mm with low-profile memory)
Top Mounted 140mm / 280mm Radiator & Fan Combined Thickness Up to 55 mm
Front Ports
USB 3.2 Type-A 1
USB 3.2 Gen 2x2 Type-C (20 Gbps) 1
Headset Audio Jack 1
Expansion Slots
Standard 7
Vertical 0
Drive Bays
2.5" 2
3.5" 1
Fan Support
Front 3 x 120 mm / 2 x 140 mm (1 x F360 RGB Core Case Version included)
Top 2 x 120 mm / 2 x 140 mm
Bottom 2 x 120 mm
Rear 1 x 120 mm (1 x F120Q Case Version included)
Radiator Support
Front Up to 360 mm
Top Up to 240 mm (280mm with low-profile memory only)
Fan Specs
Model F360 RGB Core (Case Version)
Speed 1,700 ± 200 RPM
Airflow 50.1 CFM
Static 1.27 mm-H₂O
Noise 23.3 dBA
Fan Connector 3-pin
Fan Specs
Model F120Q (Case Version)
Speed 1,350 ± 150 RPM
Airflow 60.2 CFM
Static 1.05 mm-H₂O
Noise 24.1 dBA
Fan Connector 3-pin
