Acer P1185

1 / 3

Specifications

Device class	portable
Type of device	DLP
Recommended area of application	for the Office
Effective resolution	800x600
The number of matrices	1.0
3D support
Luminous flux (ANSI Lumen)	3200
Contrast	20000
Lamp life (hours)	4000
Lamp in eco mode (h)	6000
Number of lamps	1.0
Each lamp power (w)	200
Min. diagonal size (m)	0.584
Max. diagonal size (m)	7.62
Min. the ratio of the distances to image size	1.96
Max. the ratio of the distances to image size	2.15
Min. vertical frequency (Hz)	24
Max. frame rate (Hz)	120
Min. horizontal frequency (kHz)	15
Max. frequency (kHz)	100
Optical zoom	1.1
Keystone correction
Keystone correction type	vertical
HDMI Input
Number of HDMI inputs	1.0
VGA Input
Number of VGA inputs	2.0
Component video input
S-Video Input
S-Video inputs	1.0
Composite video input
Number of composite video inputs	1.0
Audio input miniJACK
VGA Output
Audio output miniJACK
USB Type B
Interface RS-232
Focal length (max.) (mm)	24.14
Focal length (min.) (mm)	22.04
F-number (F), Max	2.68
F-number (F), min	2.56
Input format support 480i
Input format support 480 p
Input format support 576i
Input format support 576 p
Input format support 720 p
Input format support 1080i
Input format support 1080 p
Number of built-in loudspeakers	1.0
Each loudspeaker power (w)	3.0
Motorized focus
Motorized zoom
Noise level (DB)	30
PAL
SECAM
NTSC
Width (mm)	308
Height (mm)	86
Depth (mm)	211
Weight (kg)	2.0
Lamp type	UHP
Min. projection distance (m)	1.0
Max. projection distance (m)	11.9
Zoom Digital	2.0
