BenQ MX666

1 / 5

Specifications

Device class	portable
Type of device	DLP
Recommended area of application	for the Office
Effective resolution	1024x768
The number of matrices	1.0
3D support
Luminous flux (ANSI Lumen)	3200
Contrast	13000
Lamp life (hours)	3500
Lamp in eco mode (h)	5000
Number of lamps	1.0
Each lamp power (w)	240
Min. diagonal size (m)	0.95
Max. diagonal size (m)	7.6
Min. the ratio of the distances to image size	1.51
Max. the ratio of the distances to image size	1.97
Min. vertical frequency (Hz)	23
Max. frame rate (Hz)	120
Min. horizontal frequency (kHz)	15
Max. frequency (kHz)	102
Optical zoom	1.3
Keystone correction
Keystone correction type	vertical / horizontal
HDMI Input
Number of HDMI inputs	1.0
VGA Input
Number of VGA inputs	2.0
Component video input
S-Video Input
S-Video inputs	1.0
Composite video input
Number of composite video inputs	1.0
Audio input miniJACK
Audio input RCA
VGA Output
Audio output miniJACK
USB Type A
USB Type B
Interface RS-232
Ethernet Interface
Wi-Fi
Focal length (max.) (mm)	21.88
Focal length (min.) (mm)	16.88
F-number (F), Max	2.87
F-number (F), min	2.59
Input format support 480i
Input format support 480 p
Input format support 576i
Input format support 576 p
Input format support 720 p
Input format support 1080i
Input format support 1080 p
Number of built-in loudspeakers	1.0
Each loudspeaker power (w)	10
Noise level (DB)	33
PAL
SECAM
NTSC
Width (mm)	312
Height (mm)	104
Depth (mm)	244
Weight (kg)	2.65
Number of audio inputs RCA	1.0
USB Type A interface quantity	1.0
